Wood Chips Burner

We supply newest design wood chips burner machine, which is adopt wood chips as combustion fuel, it's energy saving, environmental friendly, lower costing.

Send Inquiry
Product Details

Wood Chips Burner


1. Product Introduction of the wood chips burner

Our wood chips burner machine has many patented technologies. It's a newest energy saving burner machine, which can use wood chips as combustion fuel, and its' a best option to replace Oil/Gas/Electricity burner machines to save 30-60% of the fuel cost. It would be appreciated to match energy saving and environmental protection policy of the world. In the industrial, for conversion no need to change entire existing system, only to replace existing burner or combustion system with rice husk Burner. Mainly used in industrial boiler to support hot water and hot air or other heating system.


2. Product Parameter of the wood chips burner

Item No.

GV-30-GGV-45-GGV-60-GGV-80-GGV-100-GGV-120-GGV-180-GGV-240-GGV-360-G

Output Power

Kcal

30×104

45×104

60×104

80×104

100×104

120×104

180×104

240×104

360×104

Efficiency

%

90%

Applicable Fuel


biomass/wood chips/wood pellets etc.

Fuel Consumption

Kg/h

104

156

208

278

347

417

625

833

1250

Power Consumption

KW

1.9

2.1

3

3.5

4.5

5.4

6

8

12


3. Product Feature of the wood chips burner

1) Applicable fuel : 6-12mm Wood Chips

2) Output power :0.3-6.0 million kcal;

3) Feeding system: Automatic Smart.

4) Ignition system: Automatic;

5) Damper adjustment: PLC;

6) Cylinder combustion chamber cooling mode: Air-cooling systems, better insulation furnace, hot air recycling, heat efficiency 20% higher than the traditional dry or water-cooling system;

7) Combustion chamber temperature: 1350 ℃

8) Output temperature: Maximum 1100 ℃

9) Burner Outer Tube Material: 316 S;

10) Burner Body: Carbon steel pained;

11) Structure more compact, Size more smaller, suitable for more applications;

12) Fire observer in feeding system, easy to observe combustion performance;

13) Unique anti-back fire, anti-stuck material design, security and stability;

14)Fully functional, with no material alarm, optional auto ignition mode, emergency stops, a variety of standard features such as switching operation;

15) Less ash, no clinker, really clean and low carbon;

16) Low heat losses, high heat efficiency, energy saving;


4. Production Details of the wood chips burner

1) Double hopper. The upper hopper will select the unregular size of wood chips by meshwork vibrating screen;

2) Can be operated with biomass pellet, Wood chips, PKS. Suggested size of wood chips no bigger than 3-5CM see below photo:

wood chips burner2675.png

3) PLC & VFD control panel, feeding and air supply can controlled automatically;

4) Auto Feeding system, no stuck no fire back;


5. Economic Analysis of the wood chips burner

Fuel name

Diesel

Gas

Electricity

Wood chips

Heat Value

10200kcal/kg

8500kcal/m3

860kcal/kw

3500kcal

Price

8RMB/Kg

4.5RMB/M3

1.1RMB/Kwh

0.6RMB/Kg

Burning consumption

65kg

76.9m3

780kw

165kg

Fuel costs

520RMB

346 RMB

856 RMB

99RMB

Biomass fuel efficient than

81%

71%

88%



6. Conversion program of the wood chips burner

wood chips burner3210.png

wood chips burner3223.png


7. Product Qualification of the wood chips burner

wood chips burner3237.png


8. Deliver, Shipping And Serving of the wood chips burner

wood chips burner3370.png


9. FAQ

1) What's the use life of your biomass burner?

A: 5 years if you operate obey our operation manual.

2) What's the consumption per hour of your burner?

A: This is comply with the model you choose, details pls refer our catalog.
3) Which material do you use?

A: New high-temperature composite materials, like refractory powder, castable material. durable for use.

4) What's your combustion principle?

A: Suspension combustion, half fuel half air, burn furthest can up to 95% or more.

5) How about the ignition system?

A: Automtic system,  diesel & petrol either is ok.

6) How much time it takes to start the burner?

A: About 5-10minutes
7) How much time it takes to install the machine?

A: It's easy for our technicians, it depends on the equipment that you need.

8) How many kg of pellet it consume per hour ?

A: Depends on the model you choose, details will send you by email.

9) How many people it needs to run the burner?

A: Only one person .

10) Can it work continuous?

A: Yes, it can keep working for 24 hours x 7days.
11) Can it be fed automatic?

A: Yes, we have automatic feeding system.
12) Can it be customizable?

A: Yes, we can produce the burner according to different customer's special requests.
