Product Introduction
We have more than 20 years experience of manufactures high quality electric steam generator, which is widely used in small industry. For some of country with low electricity cost,It use the perfect design with automatic feeding, automatic ignition,combustion chamber and heat recovery. Our capacity is from 12kg/hr-120kg/hr steam.
Product Parameter of Electric steam generator:
| Model | Rated evaporation | Power | Rated Working Pressure | Rated Steam Temperature | Size | Weight | Working Voltage | Steam Diameter | Safety Valve | Water Inlet | Sewage outfall |
| kg/h | kw | Mpa | ℃ | L*W*H（mm） | kg | V | DN(mm) | DN(mm) | DN(mm) | DN(mm) | |
| LDR0.3-0.7-D | 300 | 216 | 0.7 | 170 | 1800*1000*1850 | 210 | 380 | 25 | 25 | 15 | 25 |
| LDR0.2-0.7-D | 200 | 144 | 0.7 | 170 | 1260*1000*1650 | 185 | 380 | 25 | 25 | 15 | 25 |
| LDR0.1-0.7-D | 100 | 72 | 0.7 | 170 | 1150*1000*1650 | 170 | 380 | 25 | 20 | 15 | 25 |
| LDR0.07-0.7-D | 70 | 48 | 0.7 | 170 | 1100*900*1500 | 160 | 380 | 20 | 25 | 15 | 20 |
| LDR0.05-0.7-D | 50 | 36 | 0.7 | 170 | 900*480*1400 | 150 | 380 | 15 | 20 | 15 | 20 |
| LDR0.03-0.7-D | 30 | 18 | 0.7 | 170 | 740*480*1150 | 100 | 380 | 15 | 15 | 15 | 20 |
| LDR0.02-0.7-D | 20 | 12 | 0.7 | 170 | 740*480*1150 | 90 | 380 | 15 | 15 | 15 | 20 |
| LDR0.015-0.7-D | 15 | 9 | 0.7 | 170 | 650*400*1050 | 80 | 220/380 | 20 | 15 | 15 | 20 |
| LDR0.01-0.7-D | 10 | 6 | 0.7 | 170 | 650*390*1000 | 70 | 220/380 | 15 | 15 | 15 | 20 |
| LDR0.005-0.7-D | 5 | 3 | 0.7 | 170 | 450*350*700 | 40 | 220/380 | 15 | 15 | 15 | 15 |
4. Product Features
1) electric steam generator for produce steam in 3 minutes, saving the fuel cost of 30 minutes combustion per day.
2) The patent temperature control technology can adjust the steam temperature according to the requirement of the user, and can prevent the dry burning and the resulting gas explosion.
3) The air inlet and drain outlet are the same diameter, reducing the boiler scaling, and increasing the service life.
4) National exemption: the boiler water volume is less than 30L, which can be free of annual inspection fee and cumbersome procedures.
5)electric steam generator with Convenient operation: Full automatic intelligent control, no need to be on duty. Can be set to either manual or automatic mode; the pressure and water level are automatically controlled by pressing the button and entering the automatic operation state. The controller can control the pressure automatically, and the control system can protect the water pump when the load changes.
Product Details electric fired steam generator
Product Qualification
Deliver, Shipping And Serving
8. FAQ
Q1.Why Choose Us ?
A:1) We're the leading manufacturer of biomass burner, hot air generator, Aluminum melting furnace, factory located in Foshan.
2) We are exporting to many countries and area, we have distributor in Malaysia, Thailand, India and Ukraine.
3) We have plenty of experience in various applications nearby ,can show you the running machine in our customer's place any time.
4) Competitive price, high quality and quick delivery.
5) Engineers are able to serve oversea.
Q2.Our Service?
1) Your letters about any question will be replied within 24 hours.
2) We can design a machine according to your request.
3) We are a team full of experienced engineers, you have any question could tell us.
4) Good after-sale service offered.
5) We could provide training lesson in your factory.
